RB22-HD Kelly Green

RB22-HD Kelly Green

Gloss Metallic HD TeckWrap European Distributor

• The thickness of film: 0.13mm
• The thickness of film with release liner: 0.29mm
• Type of film: It is an advanced polymeric multilayered film with silver coating and air release channels that help achieve smooth application and perfect finish.
• Adhesive: Henkel solvent-based acrylic adhesive, transparent, ultra-weather-resistant, viscosity 1000~3000cps, thickness 12 μm dry
• Release liner: Products that have “HD” letters in their name are with the plastic release liner (high-gloss films)
• Outdoor life: 5 years when following rules of application and use
• Warranty: 2 years when following rules of application and service
• Aftercare: PH-neutral products. Avoid hot wax or solvents.
• Dimensional Stability: 2%
• Directional: no

Install tips:

• Application: from +16°C to +24°C
• Usage from: -30°C to +50°C
• Tools: Standard squeegee with a soft buffer
• Conformability: smooth and medium curved surface
• Directional: no
• Overlap width: 3-4mm
• We recommend using a tack reducer for flat panels.
• Installation by at least two people/panel
• Don't heat up to the line where the film is lifted to prevent adhesive lines.
• Apply max 50 degrees of heat when stretching to prevent fading and marks.
• Apply soap and water over the squeegee felt to avoid scratches.
• Relax the film (heat and let it cool down) before applying it to a recess
• Apply adhesive promoter on deep recesses
• Post-heat a vinyl to 100-110°C to a recommended temperature

How Much Wrap Do I Need?

• Motorcycles: 3-5 meters
• Mini, small cars: 12-14 meters
• Convertible: 13-15 meters
• Coupe: 14-16 meters
• Sedan: 14-17 meters
• Hatchback: 14-17 meters
• Sports Car: 16-17 meters
• Station Wagon: 17-18 meters
• Sport-utility Vehicle (SUV): 17-19 meters
• Minivan: 18-20 meters
• Pickup Truck: 18-22 meters

Important note: The images, colors, and finishes on the screen are approximate. The warranty does not cover the scratching of the film.
